101-1-B-5/2D Reed Relay
$16.10 Excl. Vat, Tax and Duties
24 in stock for online purchase
Additional stock lead time: 6-8 weeks*
Key specifications
- Series
- 101
- Coil Voltage
- 5V
- Contact Form
- 1 Form B - SPST N.C.
- Coil Resistance
- 3000 Ω
Order options
Buy direct online
For small-quantity orders from available stock.
Request a quote
For larger quantities, scheduled demand or project pricing.
- No obligation
- Response within 1 business day
- Volume pricing
Pickering Series 101
- CMOS Drive SIL Reed Relays
- Up to 10 W switching
- 220V standoff
- 3000 Ω coil resistance, fantastic for low level switching and low thermal EMF
- 5 Volt coil
- Designed and manufactured by Pickering in the UK and Czech Republic (EU)
To learn more about this series click here
| Series | 101 |
|---|---|
| Coil Voltage | 5V |
| Contact Form | 1 Form B - SPST N.C. |
| Coil Resistance | 3000 Ω |
| Switching Current (Amps) | 0.5A |
| Switching Power (Watts) | 10W |
| Switching Voltage | 200V |
| Standoff Voltage | 220V |
| Diode | Yes |
| Switch Type | General Dry Reed |
| Dimensions | 55663927 × 556629 mm |
|---|---|
| PEL Contact Configuration | 1 Form B – SPST N.C. |
| PEL Switching Current (Amps) | 0.5 |
| PEL Switching Power (Watts) | 10 |
| PEL Switching Voltage | 200 |
| PEL Standoff Voltage | 220 |
| PEL Coil Voltage | 5V |
| PEL Coil Resistance | 3000 Ω |
| PEL Diode | Yes |
| PEL Depth (mm) | 7.4 |
| PEL Width (mm) | 20.1 |
| PEL Height (mm) | 12.5 |
| PEL Series | Series 101 |
| PEL Switch Type | General Dry Reed |
