124-1-A-3/2 Reed Relay
$14.80 Excl. Vat, Tax and Duties
No stock currently available
Please check distributor inventory or request a quote below
Key specifications
- Series
- 124
- Coil Voltage
- 3V
- Contact Form
- 1 Form A - SPST N.O.
- Coil Resistance
- 75 Ω
Order options
Buy direct online
For small-quantity orders from available stock.
Request a quote
For larger quantities, scheduled demand or project pricing.
- No obligation
- Response within 1 business day
- Volume pricing
Pickering Series 124
- Single Pole Reed Relays
- 0.5 Amp switching
- Very high packing density
- Stacking on 4mm x 4mm pitch
- 1 Form A
- 3 V Coil
- Designed and manufactured by Pickering in the UK and Czech Republic (EU)
To learn more about this series click here
Many benefits compared to industry-standard relays. Learn more here
Custom options are available. Learn more here
| Series | 124 |
|---|---|
| Coil Voltage | 3V |
| Contact Form | 1 Form A - SPST N.O. |
| Coil Resistance | 75 Ω |
| Switching Current (Amps) | 0.5A |
| Switching Power (Watts) | 10W |
| Switching Voltage | 170V |
| Standoff Voltage | 200V |
| Diode | No |
| Switch Type | Low Level Dry Reed |
| Dimensions | 55663927 × 556629 mm |
|---|---|
| Series | Series 124 |
| Contact Configuration | 1 Form A – SPST N.O. |
| Switching Current (Amps) | 0.5 |
| Switching Power (Watts) | 5 |
| Switching Voltage | 170 |
| Standoff Voltage | 200 |
| Coil Voltage | 3V |
| Coil Resistance | 75 Ω |
| Diode | No |
| Depth (mm) | 3.9 |
| Width (mm) | 3.9 |
| Height (mm) | 9.5 |
| PEL Series | Series 124 |
| PEL Contact Configuration | 1 Form A – SPST N.O. |
| PEL Coil Resistance | 75 Ω |
| PEL Diode | No |
| PEL Coil Voltage | 3V |
| PEL Standoff Voltage | 200 |
| PEL Switch Type | Low Level Dry Reed |
| PEL Switching Current (Amps) | 0.5 |
| PEL Switching Power (Watts) | 10 |
| PEL Switching Voltage | 170 |
| PEL Height (mm) | 9.5 |
| PEL Width (mm) | 3.9 |
| PEL Depth (mm) | 3.9 |
